Single Axis Actuators

We make full use of features of Miniature Ball Screw manufacturer and a super compact design Actuator can be achieved. This is the Unit series so that there is no need to assemble parts and design process, assembly process can be reduced. Depending on kinds of Lead Screws, wide range of products is prepared to meet the customer's needs.

  • Product outline
  • Technical description PDF
Actuators

Standard Products

Various types of Ultra Miniature Actuators are standardized and in stock, such as Ball Screws/Lead Screws or several kinds of travel amount and so on.

*Flex Actuator (FA Series)


Rolled Ball Screw type
miniature actuator Rolled Ball Screw type

Reasonable price and accuracy have been achieved by using Rolled Ball Screw.


*Rooled Ball Screw type list Series list Handling Manual
·Motor less type Series list Catalogue PDF
·2-phase Stepping Motor (Size 25 : Minebea Motor) type Series list Catalogue PDF
·5-phase Stepping Motor (Size 28 : Oriental Motor) type Series list Catalogue PDF

Precision Ball Screw type
miniature actuator Precision Ball Screw type

High accuracy in both Repeatability and Lost motion by using Precision Ball Screw.


*Precision Ball Screw type list Series list Handling Manual
·Motor less type Series list Catalogue PDF
·2-phase Stepping Motor (Size 25 : Minebea Motor) type Series list Catalogue PDF
·5-phase Stepping Motor (Size 28 : Oriental Motor) type Series list Catalogue PDF

Customized Products

The units for special environment (Clean room etc.) and Motor less type are available as Customized products.

*Compact Actuator NEMA 6 size

The most compact single axis actuator in KSS with NEMA 6 size of 2 phase stepping motor.


Compact Actuator NEMA 6 size

Realized compactness not only the body width, but total length of the Actuator by combining NEMA6 Stepping Motor using our unique coupling-less connection.


*MoBo Actuator(MA Series)

External Ball Screw type(MoBo) is built in this series, what we call MoBo Actuators.


MoBo Actuator(MA Series)

More compact design of Unit products in longitudinal dimension became reality by using Direct Motor Drive Ball Screws / Resin Lead Screws.


*Flex Actuator (FA Series)

Customized Actuators other than in catalogue can be provided as special order in accordance with your request. Accessories can be provided as an option, such as Brake unit, Motor side mounting kit, and outside photo sensor.


Resin Lead Screw type
miniature actuator Resin Lead Screw type

High cost performance type Actuator installed Resin Lead Screw. It can be used without oiling in normal environment for long term, because lubricating agent is incorporated in Resin Nut.


*Resin Lead Screw type list Series list Handling Manual
·Motor less type Series list Catalogue PDF
·2-phase Stepping Motor (Size 25 : Minebea Motor) type Series list Catalogue PDF
·5-phase Stepping Motor (Size 28 : Oriental Motor) type Series list Catalogue PDF
Solenoid Brake Unit
Solenoid Brake Unit

If Flex Actuators are operated in vertical position, Ball Screw / Lead Screw may fall down when its power is off. Solenoid Brake Unit is effective to maintain intermediate position.


Motor side mounting kit
Motor side mounting kit

This kit can shorten the Actuator length with side mounting Motor shown in Photo. Motor mount, timing pulley, timing belt and set screws are included in this kit. KSS can assemble in accordance with your request.


Photo-micro sensor
Photo-micro sensor

Sensor accessories for the purpose of putting sensor outside Actuator. Sensor dog, sensor rail, photo sensor, sensor plate and set screws are included in this kit. KSS can assemble in accordance with your reguest.

·Option Catalogue PDF

Attachments

*Driver

Driver

This series is the recommended Driver for KSS Actuators.You can choose suitable one based on your usage.

For details

Please ask KSS about the specifications other than the above.
